Quartz Chronograph
Module 5183 measures elapsed time in 1/20-second increments, up to 4 hours, 59 minutes and 59.95 seconds.
Calendar & Dial Display
The documented EF-560D display combines three analogue hands, four dials, and day and date indications.
EF-560D Visualisation Study
The dark case, integrated strap treatment and cyan accents shown here are an illustrative composition, not a Casio product specification.
Tachymeter & Dial Layout
The tachymeter-style bezel and calendar display are visual-study labels. Module 5183 documents the chronograph and calendar functions.
CASIO
EDIFICE
Name
Function
QuartzChronograph
Module 5183
The official guide identifies the EF-560D family with quartz module 5183 and specifies accuracy of ±20 seconds per month.
Battery Life
Approx. 2 years
CASIOEDIFICEthequartzmodulechronographstudy
SR927W Battery
The official Operation Guide gives an approximate two-year battery life with an SR927W battery.
Daily Accuracy
The documented accuracy is ±20 seconds per month under normal operating conditions.
ChronographDial
Three analogue hands, four dials, and day and calendar displays organise elapsed-time information around the time display.
Dial Layout
The documented configuration combines three analogue hands with four dials, including chronograph and calendar information.
Hands & Readability
The visual study keeps the time display legible against the dark dial without making an unsupported construction claim.
Tachymeter
A tachymeter-style bezel is part of this visualisation. No crystal, bezel-material or case-construction claim is made.
CaseProfile
A close visual study of the case edge, bezel, crystal and strap connection. It is an illustrative rendering, not a product specification.
StrapProfile
An integrated dark-strap study focused on the connection, rhythm and way the strap continues the case silhouette.
CASIOEDIFICEthedarkcasechronographstudy
EDIFICE Visualisation Study
The dark case, strap treatment and cyan accents are illustrative visual choices. They do not represent a Casio product configuration.
Quartz Chronograph
The official guide documents 1/20-second elapsed-time measurement, day and date indications, and analogue timekeeping.
DarkCaseStudy
Dark Case Study
